Description
The MMSZ5250B-7-F Zener Diode is a high-reliability, surface-mount voltage regulation diode designed for low-power applications requiring precise voltage control. With a nominal Zener voltage of 20 V and a power rating of 500 mW, it provides stable operation in compact circuits.
Its SOD-123 SMT package makes it ideal for automated assembly and high-density PCB layouts. The diode offers tight tolerance (±5%), low leakage, and excellent thermal stability, making it suitable for consumer electronics, automotive, industrial control, and IoT applications.
Manufactured by Diodes Incorporated, this component guarantees consistent quality and performance, making it a trusted choice for engineers and electronics hobbyists.
🟧 Detailed Description
🔹 Key Features
-
Manufacturer: Diodes Incorporated
-
Surface-mount device (SMD), SOD-123 package
-
Zener voltage: 20 V
-
Power rating: 500 mW
-
Tolerance: ±5%
-
Low leakage current
-
High thermal stability for reliable operation
-
Suitable for automated PCB assembly
🔹 Technical Specifications
-
Type: Zener Diode, SMD
-
Zener Voltage (Vz): 20 V
-
Power Dissipation (Pd): 500 mW
-
Tolerance: ±5%
-
Package Type: SOD-123
-
Maximum Reverse Voltage: Varies; see datasheet
-
Operating Temperature: –65°C to +150°C
-
Applications: Voltage regulation, overvoltage protection, clamping
🔹 Applications
-
Low-power voltage regulation
-
Overvoltage protection in circuits
-
Consumer electronics and gadgets
-
Automotive electronics
-
Industrial control systems
-
Compact PCB and IoT devices
📦 Package Includes
-
1 × MMSZ5250B-7-F Zener Diode (SMD, SOD-123)
(Bulk packs available upon request)
⚠️ Note
-
Ensure correct Zener voltage selection for your application
-
SMT soldering precautions should be followed to prevent thermal damage
✅ Why Choose MMSZ5250B-7-F Zener Diode?
✔ Precise 20 V voltage regulation
✔ Reliable 500 mW power handling
✔ Compact SOD-123 SMT package for high-density PCBs
✔ Manufactured by Diodes Incorporated for trusted quality
